Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp

Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp

  • Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp
  • Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp
Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp
جزئیات محصول:
Place of Origin: Shenzhen, China
نام تجاری: Cayera
گواهی: CE, FCC
Model Number: AHD-AP513
پرداخت:
Minimum Order Quantity: 500
Packaging Details: 655mm*435mm*450mm;45pcs /carton
Delivery Time: 1-4 weeks after get the full payment
Payment Terms: T/T 100% before shipment
Supply Ability: 50000 pcs/per year
مخاطب
توضیحات محصول جزئیات
CMOS: 1/3" CMOS Effective Pixels: 1.3Megapixel
Video Output: 1-channel high definition video output White Balance: AUTO
Minimum Illumination: 0.01Lux (0Lux IR on) TV System: PAL/NTSC
برجسته:

cctv surveillance cameras,high definition cctv camera

,

high definition cctv camera

Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp



Application



Shopping center: Crowded places, to guarantee the citizens personal and property safety

The airport: Enhance the safety of the passengers at home and abroad, to prevent criminals, reduce potential hidden

 The school:Prevent criminals illegally, to guarantee the normal order in school

 Family: Ensure safety of old person, child

 factory: Guarantee personal safety at the same time, the safety in production, improve the company's

                production efficiency

 bank: Prevent criminals illegally, to guarantee the normal order in school



 Features:



     1.15M wired  IR IP camera,

     2. Power Supply DC12V±10%

    3. Support IE,mobilephone and CMS view

    4. Support DVR

    5. Horizontal Resolution 1280H(100W)

    6. Electronic Shutter 1/50(1/60)-1/100,000sec

    7. Support mobile phone and computer monitor





SPECIFICATIONS

Product Type

AHD Camera

Image Sensor

1/3" 1.3MegapixelCMOS( NVP2431+IMX238)

Effective Pixels

1280(H)×960(V)

Horizontal Resolution

1280H(130W)

Video Frame Rate

PAL: 25fps/960P  NTSC: 30fps/960P

Electronic Shutter

1/50(1/60)-1/100,000sec

Minimum Illumination

0.01Lux (0Lux IR on)

Synchronization

Internal

TV System

PAL/NTSC

S/N Ratio

  ≥69dB (AGC Off)

Video Output

1-channel BNC HDAHD high definition video output

AWB

AUTO

BLC

AUTO

Day/Night

Auto(ICR) / Color / B/W

Noise Reduction

2D/3D

Lens

3.6mm

Power Supply

DC12V±10%

Working Environment

 -10°C~+60°C, Less than 90% RH

Transmission Distance

Over 500m via 75-3 coaxial cable











































































Product Detail:



Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp 0Waterproof IP camera with bnc output / AHD CCTV Camera 1.0mp , 1.3mp 1
