Surface Mounted Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V

جزئیات محصول:

Place of Origin:	Jiangsu China
نام تجاری:	MANORSHI
گواهی:	ISO, CE, ROHS
Model Number:	MSES12A

پرداخت:

Minimum Order Quantity:	500 PCS
قیمت:	USD0.1-0.2 Per Piece
Packaging Details:	Export Standard Package
Delivery Time:	2-3 weeks
Payment Terms:	L/C, T/T, Western Union, By Paypal
Supply Ability:	1000000PCS/MONTH

مخاطب

توضیحات محصول جزئیات

Product Name:

Piezo Transducer

Rated Voltage:

Sound pressure:

85dB min.

Current Consumption:

30mA

برجسته:

electromagnetic buzzer,5v magnetic buzzer

5v magnetic buzzer

Surface Mounted Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V

Quick Detail:

1.Size:D12mm*H7.5mm

Specifications

TYPE (UNIT)	MSES12A23P01	MSES12A23P03	MSES12A23P05	MSES12A23P12
Min. Sound Output at 10cm (dB)	80	82	85	85
Rated Voltage VDC	1.5	3	5	12
Operating Voltage VDC	1.3~2	2~5	3~7	8~15
Resonant Frequency (Hz)	2300+/-400	2300+/-400	2300+/-300	2300+/-300
Max. Current Consumption (mA)	25	30	30	30
Operating Temperature	-20 ~ +70	-20 ~ +70	-20??+70	-20 ~ +70
Storage Temperature	-30 ~ +80	-30 ~ +80	-30 ~ +80	-30 ~ +80
Weight (g)	2	2	2	2

Frequency curve

Surface Mounted Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V 0

Drawing(mm)

Active Magnetic buzzer work is direct current signal, usually labeled VDC, VDD. Because a simple oscillation circuit inside the buzzer, It can be a constant DC converted into a certain frequency of pulse signal, from beyond the alternating magnetic field, surface drive molybdenum slice vibration pronunciation. But in some active buzzer can also work under specific ac signal, It has high request on the voltage and frequency of the AC signal .
